• TRUESEAL:
TSMeX Ex, TSPe Ex
• TRITON SERIES:
T3CDS, T3CDSPB, TE1FU, TE1FUPB, T3CDSHT
• A SERIES:
A2F100, A2e100, RA2e100, A2F, A2E, RA2E, A2FRC, A2FFC, A2FHT, A2F-FF
• SS SERIES:
SS2K, SS2KPB, SS2KTA, SS2KHT
• C SERIES:
CXe, CWe, C2K, C2KHT
• E SERIES:
E1FU, E2FU, E1FX, E2FX, E1FW, E2FW
• TMC/2 Series:
 TMC, TMC2
• TMCX/2 Series:
TMCX, TMC2X, TMC2X
• PX REX Series:
PX2KREX, PX2KWREX, PX2KXREX, PX2KPBREX, PXSS2KREX, PXSS2KHCREX, PXRCREX
• PX Series:
PX2K, PX2KX, PX2KW, PX2KPB, PXSS2K, PXRC

For termination of cables in explosive atmospheres

• Unique Independent Inner Sealing
• Secure Armour Termination
• Outer Seal
• Proven Internally Enclosed Deluge Seal
• Environmental protection – by sealing on the outer cable sheath, excluding dust and moisture from the electrical or instrument enclosure.
• Earth continuity – in the case of armoured cables, when the cable gland has a metallic construction. In this case cable glands may be tested to ensure that they can withstand an appropriate peak short circuit fault current.
• Holding force – on the cable to ensure adequate levels of mechanical cable ‘pull out’ resistance.
• Additional sealing – on the part of the cable entering the enclosure, when a high degree of ingress protection is required.
• Additional environmental sealing – at the cable entry point, maintaining the ingress protection rating of the enclosure with the selection of applicable accessories dedicated to performing this function.

-60°C to +130°C (standard), -60°C to +85°C (barrier glands)

• CMP industrial cable glands conform to the latest international standards — including EN 62444, IEC 62444 and the more rigorous BS6121:Part 1:1989.
• CMP’s range of flameproof and explosion-proof cable glands has multiple-certification, allowing customers to select one gland to cover a multitude of situations including ATEX, IECEx, cCSAus and UL.

Metric M20 to M130, NPT 1/2" to 5"

• A SERIES:
A2F/US
• C SERIES:
C2KX
• TMC/2 SERIES:
TMC, TMC2
• TMCX/2 SERIES:
TMCX, TMCX2
• TC SERIES:
CG, TC
• TRITON SERIES:
TDS(T3CDS-US)
• PX REX SERIES:
PX2KWREX-US, PXSS2KREX-US,  PX2KREX-US, PX2KXREX-US
• PX SERIES:
PK2KW-US, PXSS2K-US, PX2K-US, PX2KX-US

The following cable glands have been designed, engineered and manufactured for use in hazardous (classified) locations and ordinary locations under the NEC (National Electrical Code) and CEC (Canadian Electrical Code) installation standards.

• CMP cable glands conform to the latest international standards — including EN 62444, IEC 62444 and the more rigorous BS6121:Part 1:1989.
• • Environmental protection – by sealing on the outer cable sheath, excluding dust and moisture from the electrical or instrument enclosure.
• Earth continuity – in the case of armoured cables, when the cable gland has a metallic construction. In this case cable glands may be tested to ensure that they can withstand an appropriate peak short circuit fault current.
• Holding force – on the cable to ensure adequate levels of mechanical cable ‘pull out’ resistance.
• Additional sealing – on the part of the cable entering the enclosure, when a high degree of ingress protection is required.
• Additional environmental sealing – at the cable entry point, maintaining the ingress protection rating of the enclosure with the selection of applicable accessories dedicated to performing this function.

-60°C to +130°C (standard), -60°C to +85°C (barrier glands)

Specifications and approvals ensure the provisions of a complete global solution, covering UL, ISO, ANSI, CSA and IEC standards and meeting the requirements of NEC, CEC and IEC installation codes.

Metric M20 to M130, NPT 1/2" to 5"

• POLYMERIC:
Sabre, Falcon
• METALLIC:
Trefoil Intermediate Restraint, Helios, Reliance, Solace, Themis, Valiant, Zenith, Sapphire, Cyclone I, Cyclone II, Cyclone III, Cyclone Strap, Huron, Patriot, Sovereign, Conqueror
• ACCESSORIES:
Isolation / Seperation Pad, Wire Mesh Cable Tray / Basket Clips


Cable cleats are available for a number of different applications such as rail, underground, oil and gas, mining and petrochemical.

• The range is tested in accordance with IEC 61914 to ensure that, regardless of the cable formation used on the installation, there is a suitable cable cleat.
• CMP cable cleats provide the necessary levels of resistance to electromechanical forces, where declared, and in addition achieve the following safety measures:
-Support cables and conductors.
-Reduce the mechanical load the cable may be exposed to under its own weight.
-Reduce the mechanical load the cable termination may be exposed to.

• POLYMERIC:
Sabre, Falcon: -40°C to +60°C
• METALLIC:
Valiant, Zenith: -60°C to +150°C
Solace, Themis, Helios: -60°C to +250°C
Sapphire, Huron, Reliance, Patriot, Sovereign, Conqueror, Trefoil Intermediate Restraint: -50°C to +60°C
Cyclone I, Cyclone II/III, Cyclone Strap: -50°C to +40°C


ABS, BUREAU VERITAS, DNVGL, LLOYDS, GOST R, LONDON UNDERGROUND , RMRS

• POLYMERIC:
Sabre: 10mm to 57mm, Falcon: 38mm to 135mm
• METALLIC:
Valiant, Solace: 10mm to 71mm,
Zenith: 38mm to 151mm,
Themis: 38mm to 97mm,
Helios: 10mm to 65mm,
Sapphire: 19mm to 150mm,
Huron, Reliance: 19mm to 128mm,
Trefoil Intermediate Restraint: 19mm to 270mm,
Patriot, Sovereign: 17mm to 128mm,
Cyclone I/II/III/Cyclone Strap: 24mm to 145mm, Conquerer: 23mm to 130mm
